Applied 12" General Purpose Truss
• Black Powder Coated Aluminum Tubing
• 1.9" OD 6061-T6 Aluminum Sched #40 Tube
• 0.145" Wall Thickness
• 105" OD Aluminum Bracing
• Compatible with JTE 12" GP Truss
• Weight: 55 lbs

Weight Loading Information
Length
10' Span
20' Span
30' Span
40' Span
Qty Available:
  10 ft. Sections: 6


Uniform Distribution
6,040 lbs
4,240 lbs
2,520 lbs
1,120 lbs
Center Point Load 2,940 lbs
2,122 lbs
1,364 lbs
565 lbs
