Castle Studios Productions | Colorado Batten 72 Tour

This LED striplight includes 72 1-watt LEDs with RGBWA color mixing to produce richly saturated colors, from vivid hues to warm whites. The addition of white and amber LEDs provides designers with an expanded color palette.

PowerCon™ connectors as well as direct 3-pin and 5-pin DMX in and out provide fast and easy connections. The Batten 72 can run in stand-alone mode or be programmed via DMX.

• 3, 4, 5, 6, 7, 9, 12, 15, or 18-channel RGBWA LED linear wash light
• 16 bit dimming for each color (RGBWA) and master intensity

• Built-in automated programs via DMX

• Recall custom programs via DMX

• RGBWA color mixing with or without DMX control

• Selectable, smooth dimming curves for programming versatility

• Color temperature presets (3,200 K~10,000 K)

• Additional power output: max 6 units @ 120 V, 11 units @ 230 V

• Neutrik® powerCON™ connector with loop out

• 3-pin and 5-pin DMX input and output connectors

• Adjustable feet double as hanging bracket

• Beam angle: 23° Field angle: 39.6° Lux: 669 @ 5 m

• Light source: 72 x 1 W LEDs, 18 red (350 mA), 18 green (350 mA), 18 blue (350 mA), 9 white (350 mA), 9 amber (350 mA)

• Power and current: 120 V, 60 Hz; 87 W, 1.43 A (operating)

• Power and current: 230 V, 50 Hz; 87 W, 0.78 A (operating)

• AC power: Auto-ranging 100~240 V, 50/60 Hz

• Weight: 9.8 lbs

• Size: 2.9 x 38.9 x 6.1 in

Power cables available: Edison, Powercon, L6-20, L14-20 (120v or 230v)

Road cases hold 5 fixtures each.

Qty Available: 36
