Castle Studios Productions | ColorDash Par Hex 12

Powered by 12 hex-color RGBAW+UV LEDs, the ultra-compact COLORdash™ Par-Hex 12 satisfies the need for bright ultraviolet light without a separate UV fixture. The 12 LEDs project deeply saturated colors, any variation of white, and bold UV, all without multicolored shadows. A split-yoke bracket eliminates the need for floor stands. Power linking, a locking powerCON® power input and 3- and 5-pin DMX connectors make the fixture a great addition for tours, broadcast, and live production. The COLORdash™ Par-Hex 12 also includes a built-in gel frame holder.

• DMX Channels: 3, 6, 8, 12 or 13

• Data Connectors: 3- and 5-pin XLR

• Light Source: 12 LEDs (hex-color RGBAW+UV) 10 W, (2.3 A)

• Built-in Automated Programs: Yes

• Accessory Holder/Gel Frame Size: 9.5 in (241 mm)

• Shutter/Strobe: Electronic

• Strobe Rate: 0 to 20 Hz

• Stand-Alone Color Mixing: Yes

• Beam Angle: 20°

• Field Angle: 30°

• Dimming Modes: 4

• Illuminance: 927 lux @ 5 m

• Color Temperature (range): 2800 to 10000 K

• IP Rating: IP20, indoor use

• Power Connection: Edison plug to Neutrik® powerCON®

• Power Input: Neutrik® powerCON®

• Power Output: Neutrik® powerCON®

• Power Linking: 17 units @ 120 V; 27 units @ 208 V; 30 units @ 230 V

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

• Power and Current: 96 W, 0.80 A @ 120 V, 60 Hz

• Power and Current: 95 W, 0.49 A @ 208 V, 60 Hz

• Weight: 10 lb

• Dimensions: 4.41 x 11.73 x 12.72 in

Road case holds 12 fixtures.

Qty Available: 14

* also see our H12 IP and H12X IP fixtures, which are functionally identical,
but with tn IP rating and True1 connections.
