Gobo Shot 50W LED
Gobo Shot 50W IRC is a powerful, DMX-controllable gobo projector powered by a 50-watt LED. It features a hinged gobo door for quick, easy gobo changes and includes 10 popular gobos and a gel frame holder. For customized looks, easy to change, size D gobos allow for greater projected details. Heat-free LED power allows for use of custom gobos printed on transparency film. Use the built-in digital display or optional IRC remote to control the dimmer function as well as gobo rotation and direction.

DMX Channels: 4
• DMX Connectors: 3-pin XLR
• Gobo Size: 53 mm outside, 40 mm image, 1 mm max thickness (size D)
• Light Source: 1 LED (white) 50 W (2 A)
• Strobe Rate: 0 to 20 Hz
• Beam Angle: 26°
• Illuminance: 2,937 lux @ 2 m
• Cable Length: 25 ft
• Power Linking: 9 units @ 120 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 102 W, 0.8 A @ 120 V, 60 Hz
• Weight: 10.8 lb
• Dimensions: 12 x 12.6 x 10.2 in
• Included Controllers: Gobo Shot 50W remote


Qty Available: 1
